ZipShield™ by Atrellis
Engineered Outdoor Blinds for Singapore Living
Track-guided. Wind-rated. Smart-controlled. Built to last.
Singapore's balconies deserve more than decorative curtains. Atrellis ZipShield™ is a precision-engineered outdoor blind system — imported from Australia, tested to withstand winds up to 260 km/hr, and installed by our BCA-registered team with a 5-year residential warranty.
No cords. No zippers. No gaps. Just clean lines and total control.
The 7-Part System
Every Atrellis ZipShield™ blind is made up of seven engineered components — custom fabricated to your exact measurements.
01 Side Spline (The Patent)
A proprietary PVC-core rope, wrapped in Kedar tape and acrylic lacquer, high-frequency welded to both faces of your fabric. This single component locks the blind into its tracks and is what allows the system to hold against 260 km/hr wind loads — tested by TÜV SÜD PSB Singapore.
02 Extruded Tracks
Two precision-machined vertical aluminium channels anchor the side splines. Powder-coated using Oxyplast Superdurable Polyester (Qualicoat Class 2) — the same standard used in Singapore's architectural curtain walls.
03 Roller Tube
The heart of the system. Your fabric coils around this aluminium barrel at the top of the opening. In motorised systems, the tubular motor sits entirely inside this tube — completely hidden.
04 Motor or SuperSpring®
Motorised: DC tubular motor (Somfy® or Dooya®) slots inside the roller tube.
Manual: Ziptrak's patented SuperSpring® counterbalances the blind's weight so it moves and pauses with one hand.
05 Aluminium Bottom Bar
Keeps the fabric taut and weighted. Available in Streamline (up to 5.5m) or Extra Heavy-Duty (up to 6m) — 50% stronger for wide spans and high-floor installations.
06 PestOut® Pelmet
The top housing that protects your motor, roller tube, and fabric. Features a dual brush insert that cleans the fabric on every pass and prevents insects from nesting inside. Colour-matched for a seamless finish.
07 Mounting Brackets
Stainless steel or powder-coated brackets fix the system to concrete, steel, timber, or brick. A bottom weather seal closes the final gap against rain and dust.
Fabric Options
All fabrics are custom-cut and spline-welded to your exact dimensions. No joins, no overlaps.
| Fabric | Openness | Rain Protection | Privacy | Best For |
|---|---|---|---|---|
| PolyWeave 5% | 5% | Partial | Low | Open views, partial shade |
| FiberWeave 1% Popular | 1% | Yes | Yes | Most popular in Singapore — weather + view |
| RainOut® Acoustic | <1% | Full waterproof | Yes | Noise-sensitive balconies, STC 12 rating |
| RainOut® Blackout | <1% | Full waterproof | Full blackout | Bedrooms, AV rooms |
| ClearView™ PVC | 0% (clear) | Full waterproof | None | Restaurants, panoramic high-rise views |
You Decide.
Somfy® Motor Premium
Designed and manufactured in France. 40–50mm diameter, 6–10Nm torque. IP44 splash-proof. Pairs with the Somfy® App, Amazon Alexa, and Google Home. 5-year warranty.
Dooya® Motor Value
Made in Ningbo, China — part of the Somfy® Group. 35–45mm diameter. Dual Hall sensor for precise positioning. Obstacle detection. IP44 rated. 5-year warranty.
DualDrive® Best of Both
Our most recommended configuration. Motorised for everyday convenience. Fully manual override if there's a power outage.
"Motorised when you want it. Manual when you need it."
Control From Anywhere.
- 📱
Somfy® App
iOS & Android, control individual or all blinds remotely.
- 🗣️
Voice Control
Amazon Alexa & Google Assistant integration.
- 🏠
Smart Home
Integrates with Google Home and RF-compatible smart home hubs.
- 🌦️
Auto Weather Sensors
Wind and rain triggers that close your blinds automatically.
- ⏱️
Scheduled Timers
Open at sunrise, close at sunset — even while you're away.
Baked-On Durability, Not Just Paint.
Every aluminium track, pelmet, and bottom bar is powder-coated using Oxyplast by Lea Hin — Singapore's locally-produced powder coating, manufactured here since 1982.
- Aluminium extrusions pre-treated with chrome-free chromatation etch.
- Powder electrostatically sprayed at 60–80 kV as a dry coat.
- Components oven-cured at 185–205°C for 10–25 minutes.
- Final film thickness: 60–80 µm (harder and thicker than paint).
Available Finishes
Standard Architectural (Qualicoat Class 2), Hyperdurable Fluoropolymer (Class 3), Wood Grain Image Transfer, plus Matt, Satin, Gloss, Hammertone, Metallic, and 257-colour RAL palette options.
From Enquiry to Completion
Consultation
Contact us via WhatsApp or our web form. Share your space dimensions or photos. We'll recommend the right fabric, motor, and frame finish for your specific situation.
Site Measurement
Our team visits your property for precise millimetre-accurate measurements and a full site assessment — wind exposure, mounting surface, MCST colour requirements, and invisible grille co-existence.
Custom Fabrication
Your blinds are built to order: fabric cut and spline-welded, roller tube assembled with your chosen motor or SuperSpring®, frames powder-coated in your selected Oxyplast colour.
Installation
Our 2-person team installs the bracket system, mounts the tracks, feeds the side splines into channels, connects power (motorised), and programs upper/lower travel limits.
Testing & Handover
We run full travel tests, confirm obstacle detection, pair your remote and app, and walk you through operation and basic maintenance.
Warranty Coverage
5-year residential warranty, 3-year commercial warranty, 5-year motor manufacturer warranty (Somfy® & Dooya®), supported by a BCA-registered, licensed renovation contractor.
Specifications At a Glance
| Max Width | 6m (PanoView® — single blind, no centre post) |
| Max Height (Manual) | 4.7m |
| Max Height (Motorised) | 6m |
| Wind Rating | 260 km/hr static (TÜV SÜD PSB Singapore) |
| Motor Frequency | 433 MHz RF |
| Motor IP Rating | IP44 (splash-proof) |
| Min Install Width | 450mm (manual) / 800mm (motorised) |
| Mounting Surfaces | Concrete, steel, timber, brick |
| Frame Coating | Oxyplast Powder Coat — Qualicoat Class 1, 2, or 3 |
| Smart Integrations | Somfy App, Alexa, Google Home, weather sensors |
| Residential Warranty | 5 years |
| Commercial Warranty | 3 years |
The Art of Refined Living
Sealed, automated, and engineered for Singapore.
